When it comes to roofing, metal purlins are a critical element needed to give the structure proper support. Though we do not do installations ourselves, Western States Metal Roofing has been providing contractors with the materials required for a successful installation for over two decades.

Does metal roof need purlins?

In general, purlins are used instead of traditional decking when it comes to metal roofs. ... Decks can help support the enormous weight of roofing more easily, and therefore are recommended for larger projects, like industrial and commercial metal roofing.

Do I need roof purlins?

The purlins help the wooden shingles maintain the perfect angle for shed-ding water away from the structure while also separating them just a little bit. That way, they could dry more easily after rainfall in order to avoid rot and unnecessary damage, thus extending their lifespan quite significantly.

Are furring strips necessary for metal roof?

When installing a metal roof over an existing roof, insulate the spaces between the wood strips with rigid insulation to prevent condensation before installing the roofing. You also need to add furring strips. ... Twenty-four inches is a common spacing of furring strips for a metal roof.

Can you put metal roofing directly on rafters?

Metal roofing can be installed directly on open rafters. ... The vapor barrier built into such insulation helps to minimize the amount of condensation that drips down from the roof, and the insulation itself can help to keep the interior of the building at a comfortable temperature.

Roof Purlins

Can you walk on a metal roof with purlins?

All metal roofing systems, especially steel roofing, can be walked on. Proper fall protection is always important when walking on any roof – never walk on a wet roof or one that has dew on it. Never walk on metal roofing panels before they are properly fastened down.

How far apart are purlins put for a tin roof be?

The purlin are ultimately used to fasten the roof steel providing a diaphragm effect, along with the siding, when properly engineered and installed. Spacing is typically 24″ on center in low snow loads and is reduced based upon truss span and snow load.

Can you put a metal roof over shingles without furring strips?

You should not attach metal to asphalt shingles without furring out the roof first. Install radiant barrier, install 1"X4" battens, install metal.

Can I use 1x4 for purlins?

Re: Purlin Size

Many people around here use 1 x 4 on 30 inch spacing with rafters on 24" centers. I use 24 inch spacing on purlins with rafters on 24 inch centers.

What do you use for purlins on a metal roof?

Kiln-dried softwood is recommended for purlins or decking (pine, fir, hemlock, and spruce). Hardwoods are difficult to fasten into without splitting and contain tannic acids that are corrosive to metal panels.

What is the purpose of roof purlins?

Purlins provide additional support for the roof: They create a horizontal “diaphragm” that supports the weight of your building's roof deck – whatever material you use for the roof itself. They also help make your entire roof structure more rigid.

What is the purpose of purlins?

Purlin plates are beams which support the mid-span of rafters and are supported by posts. By supporting the rafters they allow longer spans than the rafters alone could span, thus allowing a wider building.

Should a metal roof be installed over battens?

By design, some metal roofs MUST be installed over battens, some MUST NEVER be installed over battens, and some can be installed over battens OR solid decking. So, whichever way you go, it's important to choose the right product and install it per manufacturer specifications.

Can standing seam roof be installed on purlins?

Standing seam roofs can also be installed over purlins (horizontally running 1×3 or 1×4 furring strips) or over boards. It is also recommended to install standing seam over a roofing underlayment such as roofing felt (tar paper) or synthetic underlayment.

How thick should purlins be for metal roof?

The substructure to which the metal panels are fastened must be properly spaced and sufficiently thick to provide a roof or wall system able to meet required design loads. A 2" nominal lumber thickness or 1" nominal thickness are both acceptable purlins.

What size should my purlins be?

The sizes are as follows: A four-inch purlin can span 12 feet. A six-inch purlin can span 18 feet. An eight-inch purlin can span 25 feet.

How far apart should rafters be on a metal roof?

Both 16 inches and 24 inches are common measurements for rafter spacing.

What is the best underlayment for a metal roof?

Synthetic underlayment, like Barricade^® UDL Select, is better suited for metal roofing than asphalt felt because it provides up to 30 degrees cooler surface than black underlayments. It also has excellent UV protection (up to six months) and offers a 30-year limited warranty.

Is decking required under metal roof?

As long as the interior of your roof is protected from moisture accumulation, underlayment is not required, though homeowners planning to insulate their house heavily may choose to install plywood to protect their investment.

What is the minimum spacing of purlins?

How to Install Purlins. In order for the sheets to be easily fixed to the purlins, as a rough guide they should be at least 50mm wide. When positioned, roof purlins should be spaced no further than 1.2 metres apart when using sheeting with a thickness of 0.7mm, and 1 metre when using 0.5mm sheeting.

How do I support my roof purlins?

Roof purlins are usually supported by 2×4 or 2×6 posts or struts. The posts will be spaced in four-foot distances for 2×4 purlins, while 2×6 purlins have them spaced at six feet apart. If the space between the posts is bigger than eight feet, a brace will be needed to avoid buckling.

How do you walk on a metal roof without damaging it?

General advice is: Walk closest to the areas around the decking, avoiding laps and ribs. Wear soft-soled shoes. If it feels like you've got debris underfoot, then be careful not to grind it in or you could damage the metal surface.

How do you walk on a metal roof without slipping?

Metal Roof Safety Walking Tips

Wear soft, rubber-soled shoes for the best traction. Position your ladder as close to where you need to be on the roof, but away from any known weak spots. It should extend at least 3 feet above the roof edge so you have something to hold onto.
